Specification
Unlock way: Fingerprint
Finger print Qty: 10pes fingerprint
Charging type: Micro-USB
Emergency unlock: Mos code
Standby time: Half an year
Raw material: kirsite
Size: 76*46*13 mm
IP grade: IP56
Working temperature: -10~50°C
Register 2fingerprint for the 1st time
Before registered any fingerprint can unlock.
1. Unlock the lock with the fingerprint you want registered, and don’t release the finger until the blue light on
2. Press the same finger on different position about 10times then the green light on(if 2times the same position, the light will be red color)
3.Registered the second fingerprint When the green light on, do the above step again, when it success, the green light off.
Register more fingerprint
1. Unlock the lock don’t release until the blue light on
2. Use the new finger press the lock several times until the blue light off then stop. It will be failed if over time, then need do above step again.
Emergency code setting(Morse code)
1. After setting the fingerprint. Unlock the lock and dont release the finger until the light on white color, then release the finger, the light will be green color.
2.When the light on green color,begin setting the 1st number of the Morse code, pressing one time means number 1, pressing two times means number 2, For example, the ist number you want it be 5, then you press your finger 5times. then stop pressing and waiting the light change to blue color.
3.When the light on blue color,use the same finger setting the 2nd number of the Morse code. For example the 2nd the number is 6, then you press 6tiems, then stop pressing and waiting the light off.
4.Whenthelightoff,pleasedorememberthe number you set on green light and blue light. That is the Morse code.
Emergency code unlock(Morse code)
1.When all the finger can’t unlock the lock, use any one of your finger press the lock until the light on white color. Then release the finger the light will change to green color.
2.When the light on green color, press the 1 number you set before. Then wait the light change to blue color. When the light on blue color, press the 2nd number you set before. If the above 2numbers is not correct the light will be red color and flickering. Then please use the right number do the above 2steps again until the lock unlock. After the lock unlock by the Morse code the lock will restore to the factory setting.
3.If you dont set the Morse code, the default setting Morse code is 33(green light press 3times, bule light press 3times)
Restore factory settings
1. Don’t take away the finger after unlock, until the red light on.
2.When the red light on, and release the finger, all the fingerprint and Morse code are removed. The lock restore factory setting.
Charging prompt
1.When the fingerprint is unlocked, the red light flashes continuously, indicating that the voltage is low.
2.After inserting the charging line,the red light is on and charging is in progress.
3.When the red light goes out, it means it is full. When you get the product at the first time, please fully charge it before using it.
